Hirschmann BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX BRS50 12-Port Managed Switch
Request a quote for Hirschmann BRS50-00122Q2Q-ETCZ BOBCAT switch with eight Gigabit RJ45 ports and four multi-speed SFP slots.
Hirschmann BRS50 12-port BOBCAT managed switch
Hirschmann BRS50 12-port BOBCAT managed switch
HKXY supplies the Hirschmann BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX BOBCAT managed Ethernet switch for compact industrial-network installations.
This configuration provides eight Gigabit RJ45 ports and four multi-speed SFP slots, delivering flexible copper connectivity and fiber uplinks in a compact, fanless DIN-rail device.
Customers can contact HKXY for current price, availability, technical documentation and worldwide delivery options.
Product Identification
• Brand: Hirschmann
• Manufacturer group: Belden
• Product family: BOBCAT BRS50
• Complete configuration: BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX
• Configurator part number: 942170999
• Product type: Managed industrial Ethernet switch
• Installation: DIN rail
• Total network ports: 12
• Copper ports: 8 × 10/100/1000BASE-T RJ45
• Fiber uplinks: 4 × SFP slots
• SFP data rates: 100/1000/2500 Mbit/s
• Local management interface: USB-C
• Design: Fanless
The full configuration string must be used when requesting or confirming an order. The number 942170999 alone refers to the configurable BOBCAT platform and is not a unique finished-product number.
Eight Gigabit RJ45 Access Ports
The eight copper ports support standard Ethernet connections over twisted-pair cabling.
They can be used to connect devices such as:
• PLCs
• HMIs
• Industrial computers
• Remote I/O stations
• Variable-frequency drives
• Machine controllers
• Engineering stations
• Ethernet-enabled instruments
Twisted-pair Ethernet connections typically support cable lengths of up to 100 meters when suitable cabling and installation practices are used.
Four Multi-Speed SFP Uplinks
The four SFP slots support compatible fiber transceivers operating at:
• 100 Mbit/s
• 1000 Mbit/s
• 2500 Mbit/s
Multi-speed SFP capability helps facilities upgrade backbone capacity without replacing the entire switch.
Customers should select the SFP modules separately according to:
• Single-mode or multimode fiber
• Required transmission distance
• Connector type
• Data rate
• Temperature requirement
• Environmental rating
SFP transceivers should not be assumed to be included unless they are specifically listed in the quotation.
Compact Control-Cabinet Design
The 12-port version is intended for installations where cabinet space is limited but both copper access ports and fiber uplinks are required.
Its fanless DIN-rail construction helps simplify installation in industrial control cabinets. The absence of a cooling fan also removes a moving component that would otherwise require maintenance.
The ETC hardware configuration identifies an extended-environment version with redundant DC input capability and a compact IP30 housing configuration.
The final housing material, temperature limits, conformal-coating specification and approvals must be checked against the technical data sheet for the complete product code.
Redundant DC Power Capability
The BRS50 platform supports two DC power inputs. When connected as part of a properly designed redundant power system, the second input can help maintain operation if one supply source fails.
This feature is valuable in applications where loss of network communication could interrupt production or reduce system visibility.
Power connections and grounding must be installed by qualified personnel according to current Hirschmann documentation.
Managed Industrial Networking
Depending on the configured HiOS software package and firmware version, the BRS50 BOBCAT platform may provide functions such as:
• VLAN configuration
• Quality of Service
• Multicast management
• Network diagnostics
• Link monitoring
• Port security
• Access control
• Industrial redundancy protocols
• Traffic prioritization
• Time-sensitive networking support
Before purchasing, confirm every required protocol and software feature. Similar-looking BRS50 hardware can be supplied with different software levels.
Typical Applications
The BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX is suitable for:
• Compact machine-control cabinets
• Production cells
• Packaging machinery
• Material-handling systems
• Water-treatment equipment
• Power-distribution automation
• Transportation systems
• Industrial building networks
• Process-control skids
• Remote automation panels
• OEM machine projects
• Network-modernization projects
When Should You Choose This 12-Port Version?
This configuration may be appropriate when:
• Eight Gigabit copper ports are sufficient
• Four fiber uplinks are required
• Cabinet space is limited
• Fanless DIN-rail installation is preferred
• 2.5 Gigabit fiber capability is required
• Redundant DC power inputs are needed
• Extended-environment construction is specified
Compared with the 24-port model, this version is better suited to smaller network nodes and distributed control cabinets.
12-Port vs. 24-Port BRS50
Choose the 12-port model when:
• The installation requires up to eight copper devices
• A compact footprint is important
• The network is distributed across multiple cabinets
Choose the 24-port model when:
• The cabinet contains more Ethernet devices
• Twenty local Gigabit copper ports are needed
• One high-density switch is preferred over several smaller switches
Both configurations provide four SFP uplink slots, but their physical port density and housing configuration differ.
Information Required for a Quote
Please provide:
• Complete configuration:
BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX
• Configurator number: 942170999
• Required quantity
• Delivery country and postal code
• Required delivery date
• Required approvals
• Required firmware or software level
• Required SFP modules
• Existing switch-label photo, if replacing a unit
Request a Quote from HKXY
Contact HKXY for the latest Hirschmann BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX price, availability and lead time.
Email: becky@hkxytech.com
Mobile / WhatsApp / WeChat: +86 15972186287
[GET BRS50 12-PORT PRICE]
HKXY can help verify the complete configuration and provide information about sourcing, technical documents, compatible SFP modules and international shipping.
Important Ordering Notice
Do not use only 942170999 when submitting an order. Multiple Hirschmann BOBCAT configurations can share this configurator base number.
Always provide the complete product code:
BRS50-00122Q2Q-ETCZ99HHSEAXX.X.XX
